I’ve been asked for notes about this a few times. So here’s a blog post instead.
A coworker is working on scripting our updates. We lost the Luminis Message Adapter settings in applying the patch to the environment we provide to our clients. Fortunately, those settings are maintained by us not our clients. So I pushed those settings back very easily. Unfortunately, it points to the need to capture the settings for the potential purpose of restoring the settings.
In Oracle databases, this is pretty easy. As the schema user, run the following. It does some intentional things. First, we have multiple institutions, so the breaks make identifying which institution easier. Second, the same label for multiple forms gets confusing, so I am sorting by setting description id under the theory these ids are generated at the time the page is created, so the same tools will float together. (The last modified time stamp is probably unnecessary, I used it in an earlier version and left it just in case Vista for whatever reason added a new setting for the same label instead of modifying the existing one.)
col lc_name format a50
col setting_value format a80
col label format a80
col lock format 999
col child format 999
clear breaks computes
break on lc_name skip 1
select learning_context.name lc_name, settings_description.label, settings.setting_value,
settings.locked_flag “lock”, settings_description.inheritable_flag “child”
from learning_context, settings, settings_description
where settings.settings_desc_id = settings_description.id
and settings.learning_context_id = learning_context.id
and learning_context.type_code in (’Server’,'Domain’, ‘Institution’,'Campus’,'Group’)
order by learning_context.name, settings.settings_desc_id, settings.lastmodify_ts
/
An example of the multiple forms issue is external authentication. CE/Vista provides an LDAP (A) and an LDAP (B). The settings_description.label for both is contextmgt.settings.ldap.source. The settings_description.name for both is source. It looks like each of the two identical labels has a different settings.settings_desc_id value depending on whether it is A or B. To me it seems lame to use the same label for two different ids.
The most vulnerable parts of the application to lose settings during an update are the System Integration settings. A mismatched Jar on a node will wipe all the settings associated with that Jar.
However, I can see using this to capture the settings as a backup just in case an administrator or instructor wipes out settings by mistake. Yes, this is scope creep.
Contexts: As a server admin, I maintain certain settings and push those down. Each client has control over some other settings and may push those down from the institution context. Maybe some are creating division and group admins? Maybe some instructors are changing things at the course or section levels. I may end up capturing everything?
Restoration: The whole purpose of preserving the settings is to restore them later. There are a couple methods in theory:
- Providing the settings to a human to re-enter. The labelling issue makes me question the sanity of trying to explain this to someone.
- Update the database directly would just need settings.id ensure it is the right location. Maybe dump out the settings in the format of an update command with labels on each to explain the context? Ugh.
If settings were not so easily lost, then this would be so much easier.
View: Another table of interest is the settings_v view. (Redundant?) The only reason I don’t like this view is it reports the values for every learning context which makes reporting off it much, much longer. For example, the encryption key for a powerlink is listed 8 places in settings/settings_description and 18,769 places in settings_v.
